主要技术参数:
|
参数(Item): 型号(Model): |
CK6150B |
|
|
加工能力 CAPACITIES |
床身上大回转直径Max.swing over bedmm |
500 |
|
刀架上大回转直径Max.swing over arriagemm |
290 |
|
|
大车削长度Max truning length |
1000 |
|
|
床身宽度Bed width |
390 |
|
|
行程 |
X轴行程Xaxis travelmm |
295 |
|
Y轴行程Yaxis travelmm |
2505 |
|
|
主轴 |
主轴转速范围Spindle speed rpm |
9-1600无变速 |
|
主轴端部尺寸Spinele nosemm |
C6 |
|
|
主轴内控锥度Spindle taper |
MT6# |
|
|
主轴通孔直径Spindle hole |
82 |
|
|
刀架 |
刀具数量Number of stations |
4(6) |
|
刀柄尺寸Tool shank sizemm |
25×25 |
|
|
换刀时间Indexing timesec |
2.0 |
|
|
进给 |
X轴快速进给Rapid traverse of X axismm/min |
3000/4500 |
|
Z轴快速进给Rapid traverse of Z axismm/min |
4000/6000 |
|
|
每转切削进给量Cutting feed X and Z axismm/r |
0.005-100 |
|
|
尾座 |
尾座套筒锥度Taper of tailstock sleeve |
MT4#/MT5# |
|
尾座套筒直径Dia.of tailstock sleeve |
75 |
|
|
尾座套筒行程Travel of tailstock sleeve |
150 |
|
|
电机 |
主电机功率Main motor power kw |
7.5 |
|
X轴、Z轴电机X and Z axis motor Nm |
4, 6 |
|
|
长×宽×高L×W×H mm |
2600×1400×1850 |
|
|
净重Net weight kg |
2700 |
|
